Truck Crane – Model XCT25L4_Y

XCMG Australia presents the Truck Crane model XCT25L4_Y, meticulously designed for precise and efficient material handling in construction and industrial settings. This versatile crane offers robust strength and advanced features, ensuring reliability and performance for heavy-duty tasks. Trust XCMG Australia’s commitment to delivering innovative solutions, providing the ideal truck crane for your construction needs.

Key Specs

Maximum Tip Height

43.2 m

Fly Jib

8.3 m

Boom

34 m

Total Rated Lifting Capacity

25 t

Overall Length	12535 mm Right Hand Drive – Swing -away Jib 12942 mm Right Hand Drive – Underslung Jib
Overall Width	2550 mm Right Hand Drive – Swing -away Jib 2550 mm Right Hand Drive – Underslung Jib
Overall Height	3420 mm Right Hand Drive – Swing -away Jib 3920 mm Right Hand Drive – Underslung Jib
Wheelbase	4425 + 1350 mm
Front and Rear Overhang	2442 mm Front 2420 mm Rear
Front and Rear Extension	1528 Front / 370 Rear mm Swing-away Jib 1935 Front / 370 mm Rear Underslung Jib
Total Vehicle Mass (In Travel Configuration)	27500 kg
Axle Load	1st Axle – 5900 kg 2nd Axle – 10800 kg 3rd Axle – 10800 kg
Engine Model	SC7H260Q3
Engine Rated Power	192 kW 2200 rpm
Maximum Net Power	188 kW 2200 rpm
Maximum OutPut Torque	1000 Nm 1400 rpm
Maximum Travel Speed	> 85 km/h
Minimum Stable Travel Speed	2 ~ 3 km/h
Minimum Turning Diameter	< 20 m
Minimum Turning Diameter at Boom Tip	< 25 M
Minimum Ground Clearance	261 mm
Maximum Steering Angle	±42^o
Minimum Ground Clearance	530 mm
Approach Angle	16.5 ^o
Departure Angle	13 ^o
Breaking Distance (at 30 km/h)	< 10 m
Maximum Gradeability	>42%
Fuel Consumption Per 100 km	30 L
Exterior Noise Level	<120 dB(A)
Noise Level at Seated Position	<90 dB(A)
Maximum Total Rated Lifting Capacity	25 t
Minimum Rated Working Radius	3 m
Turning Radius at Turntable Tail	3425 mm

Maximum Load Moment	965 kN.m Base Boom 623 kN.m Fully Extended Boom 370 kN.m Fully Extended Boom + Jib
Outrigger Span	5.23 m Longitudinal 6.4 m Lateral
Hoist Height	10.9 m Base Boom 34.5 m Fully Extended Boom 43.2 m Fully Extended Boom + Jib
Boom Length	10.6 m Base Boom 34 m Fully Extended Boom 42.3 Fully Extended Boom + Jib
Jib Offset Angle	0 , 15, 30 Swing Away Jib 5, 15, 30, Underslung Jib
Boom Raising Time (Speed)	< 35 s
Boom Fully Extending Time (Speed)	< 53 s
Maximum Slewing Speed	> 3 r/min
Outrigger Extending and Retracting Time	< 20 s Horizontal Outrigger Retracting Time < 25 s Horizontal Outrigger Extending Time < 20 s Vertical Outrigger Retracting Time < 25 s Vertical Outrigger Extending Time
Hoisting Speed ( Single Line, 4th Layer, No Load)	>135 m/min Main Winch >135 m/min Auxiliarty Winch

Lorem ipsum dolor sit amet, consectetur adipiscing elit. Ut elit tellus, luctus nec ullamcorper mattis, pulvinar dapibus leo.

Load and Capacity Charts

These charts display the maximum safe lifting capacities of the crane under various configurations, such as boom length, boom angle, and counterweight settings
