Hydraulic Large Excavator – Model: XE500LC
Unleash the Power and Performance of the XCMG XE500LC Hydraulic Large Excavator, Your Ultimate 50-Tonne Excavation Solution. Elevate Your Projects with XCMG’s Proven Strength and Reliability, Setting New Standards for Excavation Excellence.
Product Overview
| Operating Weight | 52000 kg |
| Engine | Cummins QSX12 |
| Power | 336 kW/1,800 rpm |
| Max Torque | 1,898 Nm/(1,200-1,600) rpm |
| Flow Range | 2×384 L/min |
| Bucket Digging Force | 269 kN |
| Arm Digging Force | 205 kN |
| Swing Speed | 9.2 r/min |
| Main Pump Type | Two piston pumps |
| Emergency Stops | Included |
| Buckets | 2.8 m³ |
| Fuel / Cooling | Diesel / Water Cooling |
| No of Cylinders | 6 |
| Alternator | 70A |
| Fuel Tank Size | 650L |
| Travel Speed (Low – High) | 5.4/3.2 km/h |
| Traction Force | 370 kN |
| Gradeability | ≤35o |
| Overall Length | 12310 mm |
| Overall Width with Pedal | 3574 mm |
| Overall Height | 4100 mm |
| Overall Track length | 5385 mm |
| Overall Height of Platform | 3095 mm |
| Minimum Ground Clearance | 518 mm |
| Tail Swing Radius | 3645 mm |
| Overall Width of Chassis (Without Pedal) | 3340 mm |
| Track Gauge | 2740 mm |
| Track Height | 31225 mm |
| Counterweight Ground Clearance | 1359 mm |
| Track Shoe Width | 600 mm |
| Boom Length | 6900 mm |
| Dig Depth & Reach | 7755/ 10980 mm |
| Maximum Digging Height – Std Arm | 10980 mm |
| Maximum Digging Depth – Std Arm | 7755 mm |
| Maximum Dumping Height – Std Arm | 7630 mm |
| Maximum Vertical Wall Digging Depth – Std Arm | 6805 mm |
| Minimum Swing Radius – Std Arm | 3920 mm |
| Maximum Depth Cut for 2,240 mm(8 ft)Level Bottom | 7615 mm |
| Engine |
| Cummins QSX12 |
| Hydraulic system |
| Breaker Pipe |
| Quick Coupler Pipe |
| Thumb |
| Hydraulic Oil ISO VG 46 |
| Electric Proportional Joystick on the Left and Right |
| Gauge Pressure Monitor |
| Cab & Interior |
| Pressurized Cab |
| Air Suspension Seat with Heater |
| Left and Right Control Box |
| Sliding Upper Door Windows |
| 70/30 Split Front Windshield |
| Bi-directional Air Outlet Air Conditioner with Defroster Automatic with Pressurization Function |
| Color LCD Display with Warning Messages, Filter/Fluid Change Information and Hours of Operation |
| Double Stereo Speakers |
| Cup Holder |
| Coat Hook |
| Washable Floor Mats |
| Seat Belts |
| High-low Speed Shift |
| One Click Power Boost Mode |
| Sunshade |
| Top Hatch |
| Intermittent Multi-speed Wiper |
| File Folder |
| Rear Window Emergency Exit |
| Emergency Escape Hammer |
| Undercarriage |
| Track Guards Located in Left and Right Tracks |
| 2 × 9 Bottom Roller |
| 2 × 2 Carrier Roller |
| Tow Ring on the Bottom Frame |
| Track with 2×50 Joint,600 mm（24″）Double Grouser Shoes |
| Guard Kits: Bottom Sealing Plate of Undercarriage, Sealing Plate of the Traveling Motor |
| Electrical System |
| Battery 2×650 CCA (4 Accumulator) |
| Alternator 70 A |
| 7.5 kW Starter Motor |
| 12 V Power Port |
| 5 V USB Interface |
| Rightview Camera |
| Rear Camera |
| Travel Alarm with Switch |
| Rotating Beacon |
| Two Front Working Light on the Cab (LED） |
| Two Working Lights on the Working Device (LED) |
| Interior Light in the Cab |
| Safety |
| Anti-collision Beam |
| Cab Lock |
| Work Light (1 on boom) |
| Emergency Stop Switch |
| Warning Horn |
| Quick Coupler Button with Alarm |
| Isolation Plate Between Engine and Oil Pump Compartment |
| Battery Disconnect Switch |
| Safety Handrails and Pedals |
| Anti-skid Plate/Anti-skid Sticker |
| Hydraulic Safety Locking Lever |
| Rearview Mirrors Left and Right |
| Counterweight Rearview Mirror |
| Anti-burst Valve on the Boom |
| Anti-burst Valve on the Arm |
| ROPS |
| Fall Over Protective Structure |
| Upper Protective Net on Front Windshield |
| Lower Protective Net on Front Windshield |
| Other |
| Standard Arm 2900 mm |
| Undercarriage |
| Steel Tracks 230 mm |
| Hydraulic system |
| Hydraulic Oil ISO VG 32 |
| Hydraulic Oil ISO VG 68 |
| Cab & Interior |
| Rain Visor (Not mounted When Front Upper Protective Net Exists) |
| Double Laminated Windshield and Other Toughened Windows |
| Electrical System |
| Rightview Camera |
| DAB Bluetooth Digital Radio |
| Other |
| Long Arm 1120 mm |
| General Purpose Bucket 0.04 m³ |
| Quick Coupler Attachments i.e: Hammer or Clamshell (Contact Us for More Options) |
