Scissor Lift – Model XG1012AC

The XCMG Australia XG1012AC Compact Scissor Lift is designed for versatile material handling in warehouses and industrial settings. With a sturdy build and advanced features, it efficiently elevates loads from 450kg to 1.5t. XCMG’s lifts combine power and agility, offering reliable solutions for various tasks. Explore our range of Electric Scissor Lifts and Outdoor Access Equipment, all engineered to enhance operational efficiency. Trust XCMG Australia for innovative material handling solutions.

Key Specs

Max. Working Height

10 m

Max Occupant Capacity

2 people

Load Capacity

450 kg

Lifting Motor

3.3 kW

Product Overview

SPECIFICATIONS

Maximum Working Height	10 m
Maximum Platform Height	8 m
Load Capacity	450 kg
Load Capacity of Extended Platform	115 kg
Maximum Occupant Capacity	2 People
Minimum Ground Clearance (Pit Protector Rising/Descending)	.11 m/0.02 m
Minimum Turning Radius (Inner/Outer Wheel)	0 m Front 2.3m Rear
Lifting Motor	3.3 kW
Lifting/ Descending Duration of Platform	29 – 40 s Lifting 49 – 60 s Descending
Maximum Travel Speed Low Level	4 km/h
Maximum Travel Speed Hight Level	0.8 km/h
Maximum Gradeability	25 %
Maximum Inclination (Side/Forward and Backwards)	1.5^o Side/Forward 3^o Backwards
Battery	24 v 280 Ah
Tyre Specifications	Non Marking and Solid 381 mm x 127 mm
Total Machine Weight	2680 kg
Overall Length	2.477 m 1.805 m With No Ladder
Overall Width	1.17 m
Overall Height	2.355 m 1.805 m Platform Folded
Working Platform Dimensions	2.27 m Length 1.12 m Width 1.246 m Height
Lenght of Extension Platform	0.9 m
Wheelbase	1.877 m
Wheel Track	1.043 m
