Double Axle Rigid Dump Truck – Model XDE440

The XCMG Australia XDE130 Double Axle Rigid Dump Truck, meticulously crafted for efficient material handling in mining, construction, and industrial environments. Engineered with robust strength and advanced features, this rigid dump truck ensures precision and efficiency for heavy-duty tasks. With capacities ranging from smaller loads to larger capacities, XCMG’s double axle rigid dump trucks seamlessly integrate power and versatility, offering a reliable solution for various earth-moving needs. Whether for mining, construction, or other industrial applications, XCMG Australia has the perfect solution in our range, featuring versatile double axle rigid dump trucks available for sale. Place your trust in XCMG Australia’s unwavering commitment to delivering innovative material handling solutions for the mining and construction industries.

Key Specs

Payload

400000kg

Rated Power

2800/ 1800 kw/rpm

Max Gradeability

19%

Total Weight

260000 kg

Product Overview

Overall Length15700 mm
Overall Width10120 mm
Overall Height80000 mm Front Canopy Height
Wheelbase6650 mm
Tire Center Distance6751 mm Front
6096 mm Rear
Total Weight260000 kg
Payload400000 kg
Gross Vehicle Weight260000 kg
Weight Distribution130000 kg (50%) Front Unloaded
130000 kg (50%) Rear Unloaded
211200 kg (32%) Front Loaded
448800 kg (68%) Rear Loaded
EngineMTU20V4000C23
Rated Power2800 / 1800 kw/rpm
Max Torque12920/ 1700 Nm/rpm
Drive4 x 2
Tyres59/80 R63
Max Speed64 km/h
Minimum Turning Clearance34 m
Maximum Gradeability19%
Minimum Ground Clearance920 mm
Loading Height7354 mm
Hoist Time28 s
Fuel Tank5300 L
Hydraulic Oil Tank1700 L
Engine Oil300 L
Cooling System1060 L
Transfer Box102 L
2:1 Stacking Standard Flat Loading183 m3
2:1 Stacking250 m3
