XCMG XLC17000 – Intelligent Lifting for Next-Gen Wind and Infrastructure Projects
Engineered for extreme power, precision, and adaptability, the XCMG XLC17000 redefines performance in wind energy, infrastructure, and ultra-heavy industrial lifting. With an immense 1,250-ton lifting capacity, advanced superlift boom configurations, and cutting-edge intelligent control systems, this crawler crane delivers unmatched stability, reach, and efficiency—especially for next-generation onshore wind turbine installation and large-scale construction projects.
XCMG XLC17000 Crawler Crane – Powering the Future of Wind Energy and Heavy Industry
Engineered for extreme lifting power, reach, and efficiency, the XCMG XLC17000 sets a new benchmark in ultra-heavy lifting—designed to meet the growing demands of wind energy, large-scale infrastructure, and industrial construction projects. With an industry-leading 1,250-ton lifting capacity, advanced superlift boom configurations, and intelligent automation, this crawler crane is purpose-built for next-generation wind turbine installation and complex heavy-duty lifts.
Boasting a maximum boom + jib combination of 194 meters, a dual-engine high-performance hydraulic system, and modular, transport-optimized design, the XLC17000 delivers precise control, operational stability, and unmatched lifting performance on even the most demanding job
Built for Precision and Performance
- 1,250-ton max lifting capacity – Unrivaled strength for turbine and infrastructure lifts
- Up to 194m boom + jib height – Massive reach for onshore wind turbine installations
- Optimized for wind energy, infrastructure, and industrial sectors – Purpose-built for high-capacity lifting
- Smart AI-assisted lifting and load protection – Advanced automation and safety systems for operational accuracy
- Modular transport-ready design – Efficient assembly, transport, and site adaptability
Trust XCMG’s XLC platform to deliver precision-engineered solutions for the future of energy and infrastructure.
Contact us today to learn how the XLC17000 can enhance your lifting capabilities!
Product Overview
| Overall Length | 15,900 mm (working) 12,600 mm (transport) |
| Overall Width | 3000 mm |
| Overall Height | 3300 mm |
| Maximum Lifting Capacity | 1,250 t – Standard Boom |
| Maximum Lifting Moment | 17,000 t·m |
| Main Boom Length | 54 m – Standard Maximum: Up to 186 + 8 m (Superlift configuration) |
| Fixed Jib Length | Up to 8 m (paired with main boom configurations) |
| Maximum Tip Height | 125 m (Standard configuration) Up to 185 m (Superlift configuration) |
| Track Width (each side) | 2,000 mm |
| Track Length | 10,000 mm Approx. |
| Car-body Counterweight | 95 t |
| Turntable Counterweight | 245 t |
| Superlift Counterweight | 550 t |
| Maximum Hook Block Capacity | 800t / 50t / 16t (multiple configurations available) |
| Engine Manufacture | Weichai |
| Engine Model | WP17G770E302 (2 engines) |
| Rated Power | 2 × 425 kW @ 2100 rpm |
| Rated Speed | 2100 r/min |
| Maximum Torque | 3,000 Nm |
| Emission Standard | Off-road China Stage III (equivalent to EURO III standards) |
| Fuel Tank Capacity | 2000 L |
| Maximum Travel Speed | 1.0 km/h (fully loaded) |
| Maximum Slewing Speed | 1.0 rpm |
| Gradeability | 30% |
| Maximum Transport Weight (Per Component) | Varies by component; approx. 35,000–40,000 kg typical |
| Cab Features | Air-conditioned cab with adjustable seating Tilting and rotating cab for improved visibility during high lifts Full-view glass design Spacious 1.25m-wide layout for operator comfort Sliding entry door |
| Safety Features | |
| Load Moment Limiter | Intelligent load management |
| Over-winding & Over-releasing Prevention | Protects hoist ropes |
| Boom Angle Limiter | Prevents unsafe boom operation |
| Anti-Mis operation Function | Avoids unintentional control inputs |
| Emergency Stop Function | Halts all operations instantly |
| Slewing Locking Mechanism | Secures crane during transport/lift |
| Advanced Monitoring System | 4-camera system with live feed in cab |
| AI Intelligent Operation & Planning | One-button lift, boom, and reeving |
| Self-Dismantling Functions | Track beam and boom components |
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Ut elit tellus, luctus nec ullamcorper mattis, pulvinar dapibus leo.
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Ut elit tellus, luctus nec ullamcorper mattis, pulvinar dapibus leo.
Need more information about the XCMG XLC17000 Crawler Crane?
Download the brochure below for detailed load capacity charts, specifications, and more!
